The SD-904 splitter is used in multiswitch systems to extract the signal from the multiswitch busAdditionally, the splitter also gives off terrestrial TV signalThe splitter has a DC transition switch that sets to the "ON" position and transmits DC voltage through the "H" paths to both branchesSet in the \"OFF\" position, it passes voltage only to one branch
SPLITTER TERRA SD-904 TV/SAT
€85.00
Shipping from warehouse: D4
Estimated shipping: Mon, Apr 29 - Thu, May 2
14 days returnUnconditional return policy
- Availability:
- moderate quantity
- Brand:
- Product code:
- SD-904 / 5907634594699
Share this product:
Specification
| Connection attenuation:: | 4 dB - SAT, 4 dB - RTV |
|---|---|
| Dc transition:: | Max. 2 A |
| Dimensions:: | 126 x 135 x 50 mm |
| Frequency range:: | 950 ... 2400 MHz - SAT, 5 ... 862 MHz RTV |
| Manufacturer / brand:: | TERRA |
| Number of inputs:: | 9 pcs. |
| Number of outputs:: | 18 pcs. |
| Operating temperature:: | -20 °C ... 50 °C |
| Scales:: | 0.75 kg |
| Selected features:: | Cast body for effective shielding and high mechanical resistance |
| Separation between outputs:: | > 30 dB |
| Warranty:: | 2 years |
