The BDI-A 30 protective plug has a protective IP54. The device is very sensitive, reacts to leakage currents from 30 mA. After each power outage, the plug should be tested again as it had been for the first connection. For detailed information on use, please refer to the instruction manual supplied with the kit.
- Nominal voltage 230 V
- Frequency 50 Hz
- IAN 30mA
- Trigger time max. 30ms
- Nominal consumption max. 3680W
- Maximum allowable short-circuit current 500A
- Nominal current 16A
- Ambient temperature at which the device can be used: -25°C to +40°C
- Protection class I
- Protection class IP54
- 2-pole separation from the mains.
- Plug with two contacts.
