| Ac: | 1 mA–10 A |
|---|---|
| Ac voltage: | 0.1 mV – 600 V |
| Capacity: | 0.01 nF–1 mF |
| Connection testing/diodes: | yes/yes |
| Dc voltage: | 0.1 mV – 600 V |
| Direct current: | 0.1 μA–10 A |
| Display: | LCD |
| Frequency: | 0.01 Hz – 50 kHz |
| Measurement category: | CAT III 600 V |
| Measurement method: | TRUE RMS |
| Model: | MM 5-2 |
| Protection: | IP 30 |
| Resistance: | 0.1 Ω–40 MΩ |
| Temperature: | –40° to +400 °C |
| Type and number of batteries: | 2 x Micro AAA/LR03 |
MM 5-1 universal digital meter
Material: impact-resistant plastic body with integrated rubber protective frame. With voltage sensor and TRUE RMS measurement method for precise measurement results, also with non-sinusoidal signal waveforms. Supplied with compact protective case, double-insulated, safe test leads and batteries.
MM 5-2. Microampere measuring ranges (400 μA DC/4000 μA DC) for ionization measurements in heating systems. HOLD, PMAX/PMIN, REL.
Despite our best efforts, we cannot guarantee that the published technical data and photos do not contain inaccuracies or errors, which, however, cannot be a basis for claims.
