Digital Passive Infrared Detector
The device is designed for transition control systems
TRANSITION CONTROL DETECTOR DS160 BOSCH VERTICAL CURTAIN
€134.58
Shipping from warehouse: D4
Estimated shipping: Tue, May 21 - Fri, May 24
14 days returnUnconditional return policy
- Availability:
- moderate quantity
- Brand:
- Product code:
- DS160 / 8717332791767
Share this product:
Specification
| Dimensions:: | 178 x 44 x 46 mm |
|---|---|
| Manufacturer / brand:: | BOSCH |
| Maximum load on outputs:: | 1 A / 30 VDC |
| Operating temperature:: | -29 °C ... 49 °C |
| Power:: | 12 V DC / 9 mA ( 38 mA - Alarm signaling ) |
| Pyroelement:: | Double |
| Range:: | 4 x 6 m |
| Scales:: | 0.16 kg |
| Sensor type:: | Passive infrared (PIR) - vertical curtain |
| Use:: | Internal |
| Violation signaling time:: | 0.5 ... 64 sec |
| Warranty:: | 2 years |
