| 10g support: | No |
|---|
| Ac input frequency: | 50/60 Hz |
|---|
| Ac input voltage: | 100 - 240 V |
|---|
| Access control list (acl): | Yes |
|---|
| Arp inspection: | Yes |
|---|
| Basic switching rj-45 ethernet ports quantity: | 8 |
|---|
| Basic switching rj-45 ethernet ports type: | Gigabit Ethernet (10/100/1000) |
|---|
| Bpdu filtering/protection: | Yes |
|---|
| Broadcast storm control: | Yes |
|---|
| Cloud-managed: | Yes |
|---|
| Configuring location settings (cli): | Yes |
|---|
| Copper ethernet cabling technology: | 1000BASE-T, 100BASE-TX, 10BASE-T |
|---|
| Depth: | 180 mm |
|---|
| Dhcp features: | DHCPv6 client, DHCP snooping, DHCP server, DHCPv6 snooping, DHCP client, DHCP relay |
|---|
| Fiber ethernet cabling technology: | 1000BASE-X, 100BASE-FX |
|---|
| Flow control support: | Yes |
|---|
| Form factor: | 1U |
|---|
| Forwarding rate: | 14.9 Mpps |
|---|
| Gigabit ethernet (copper) ports quantity: | 8 |
|---|
| Harmonized system (hs) code: | 85176990 |
|---|
| Heat dissipation: | 594.46 BTU/h |
|---|
| Height: | 44 mm |
|---|
| Igmp snooping: | Yes |
|---|
| Ip-mac-port binding: | Yes |
|---|
| Jumbo frames: | 9000 |
|---|
| Jumbo frames support: | Yes |
|---|
| Link aggregation: | Yes |
|---|
| Mac address table: | 8000 entries |
|---|
| Management protocols: | SNMPv1/v2c/v3, SNTP |
|---|
| Mib support: | RFC2925, RFC2618, RFC2620, RFC2021, RFC2819, RFC2674, RFC1213, RFC2233, RFC1643, RFC1493 |
|---|
| Multicast support: | Yes |
|---|
| Networking standards: | IEEE 802.3af, IEEE 802.3az, IEEE 802.3at, IEEE 802.1D, IEEE 802.3z, IEEE 802.3u, IEEE 802.3ad, IEEE 802.1s, IEEE 802.1Q, IEEE 802.3x, IEEE 802.1w, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3i, IEEE 802.1x |
|---|
| Number of fans: | 1 fan(s) |
|---|
| Number of queues: | 8 |
|---|
| Number of vlans: | 4000 |
|---|
| Operating relative humidity (h-h): | 10 - 90% |
|---|
| Operating temperature (t-t): | 0 - 50 °C |
|---|
| Package depth: | 400 mm |
|---|
| Package height: | 80 mm |
|---|
| Package weight: | 2.12 kg |
|---|
| Package width: | 250 mm |
|---|
| Packet buffer memory: | 4.1 MB |
|---|
| Port mirroring: | Yes |
|---|
| Power consumption (max): | 173.9 W |
|---|
| Power over ethernet (poe): | Yes |
|---|
| Power over ethernet plus (poe+) ports quantity: | 8 |
|---|
| Power source: | AC |
|---|
| Power supply included: | Yes |
|---|
| Product colour: | Black |
|---|
| Quality of service (qos) support: | Yes |
|---|
| Queue scheduling algorithms: | SP, Weighted Round Robin (WRR) |
|---|
| Rack mounting: | Yes |
|---|
| Rate limiting: | Yes |
|---|
| Security algorithms: | EAP-MD5, SSH, EAP-LEAP, SNMPv2, EAP-TLS, SSL/TLS, EAP-TTLS, SNMPv3, SNMP, HTTPS, SSH-2 |
|---|
| Sfp module slots quantity: | 2 |
|---|
| Spanning tree protocol: | Yes |
|---|
| Ssh/ssl support: | Yes |
|---|
| Storage relative humidity (h-h): | 5 - 90% |
|---|
| Storage temperature (t-t): | -40 - 70 °C |
|---|
| Switch layer: | L2/L2+ |
|---|
| Switch type: | Managed |
|---|
| Switching capacity: | 20 Gbit/s |
|---|
| System event log: | Yes |
|---|
| Total power over ethernet (poe) budget: | 150 W |
|---|
| Virtual lan features: | Voice VLAN, MAC address-based VLAN, Protocol-based VLAN, Tagged VLAN, Multicast VLAN |
|---|
| Vlan support: | Yes |
|---|
| Web-based management: | Yes |
|---|
| Width: | 294 mm |
|---|
