Tapmatic threading apparatus 70xM5,0-18

€2,586.28
Shipping from warehouse: ⁨B6⁩
Estimated shipping: Thu, Oct 16 - Mon, Oct 20
14 days returnUnconditional return policy
Availability:
large quantity
Brand:
TAPMATIC
Product code:
10718 / 4330816865781

Specification

Collets:J440, J441, J443, J445
Cutting range in steel:M5 – M18
Slot inner cone:B 18

Tapping apparatus

Design: with adjustable slipper clutch and fast return movement. Length compensation and integrated compression spring system in the cutting part. For right-hand drives .
Application: for tapping with all table and stationary drills, in which the work is based on manual feed and there is no possibility to change the direction of rotation of the spindle.
Scope of delivery: threading apparatus with restraint arm, 2 fastening wrenches and Allen key.
Note: threading apparatus for left thread available on request.

Despite our best efforts, we cannot guarantee that the published technical data and photos do not contain inaccuracies or errors, which, however, cannot be a basis for claims.
