10060416 Solid, folding legs and bottom-mounted water cooling systemThis is reduced by blade maintenance costs, prolongs the operation process and accelerates dust removal, which positively affects the speed achieved by the blade. engine power 2000 W3000 rpm. cutting angle adjustments Product features:
- - Efficiency - 2000 W motor accelerates a 400 mm diamond disc to 3000 rpm,
- - Precision - adjustment of the cutting angle in the range from 0 to 45 (vertical) and 0 to 60 (horizontal),
- - Durability - water cooling system prolongs the operation of the device,
- - Convenience - covered with a rubber coating and mounted on a guide with rollers a spacious work table (52.3 x 43 cm),
- - Security - IP54 degree of protection,
- - Mobility - folding legs and wheels mounted at the bottom of the device make it easy to carry.
- - Model - S-SAW400
- - Catalog No. - 10060416
- - Voltage / Frequency - 230 V / 50 Hz
- - Power - 2000 W
- - Degree of protection - IP54
- - Rated duty cycle - S6 40%
- - Maximum rotational speed (no load) - 3000 rpm
- - Maximum workpiece thickness at an angle of 90 - 90 mm
- - Maximum workpiece thickness at an angle of 45 - 65 mm
- - Blade tilt range - 45
- - Maximum cutting depth - 120 mm
- - Maximum cutting length - 700 mm
- - Table dimensions - 523 x 430 mm
- - Dimensions of the water tank - 472 x 1048 x 78 mm
- - Water tank capacity - 38 l
- - Disc diameter - 400 mm
- - Disc bore diameter - 25.4 mm
- - Noise level - 90 dB(A), Measurement uncertainty K = 3 dB(A)
- - Sound pressure level - 77 dB(A), Measurement uncertainty K = 3 dB(A)
- - VDE plugin - Yes
- - Power cord length - 2.4 m
- - Vibration emission value - 3.4 m/s2
- - Measurement uncertainty K = 1.5 m/s2 -
- - Dimensions (LxWxH) - 60.50 x 127.60 x 135.00 cm
- - Weight - 77,00 kg
- - Shipping dimensions (LxWxH) - 124.00 x 57.00 x 58.00 cm
- - Shipping weight - 84,00 kg
- - Stone saw S-SAW400
- - Diamond dial – 1 pc.
- - Cross screw – 1 pc.
- - Key – 1 pc.
- - Clamping tool – 1 pc.
- - Protractor – 1 pc.
- - Instruction manual
