| 3g standards: | HSPA, DC-HSPA+, UMTS |
|---|
| 3g/4g lte bands: | FDD LTE: 700, 800, 850, 900, 1800, 2100, 2600 MHz | TDE-LTE: 2300, 2500, 2600 MHz |
|---|
| 4g bands supported: | 1800, 2100, 800, 2600 MHz, 850, 2500, 700, 2300, 900 |
|---|
| 4g standard: | TD-LTE & FDD-LTE |
|---|
| 4g standards: | TD-LTE & FDD-LTE |
|---|
| Ac adapter: | yes |
|---|
| Ac adapter frequency: | 50/60 Hz |
|---|
| Ac adapter included: | Yes |
|---|
| Ac adapter input current: | 0.6 A |
|---|
| Ac adapter input voltage: | 100 - 240 V |
|---|
| Ac adapter output current: | 1.5 A |
|---|
| Ac adapter output voltage: | 12 V |
|---|
| Antenna: | 2 internal LTE antennas, 2 internal WiFi antennas |
|---|
| Antenna type: | Internal |
|---|
| Antennas quantity: | 4 |
|---|
| Basic wi-fi standard: | Wi-Fi 6 (802.11ax) |
|---|
| Baud: | 5GHz: Up to 1201Mbps | 2.4GHz: Up to 574Mbps |
|---|
| Built-in processor: | Yes |
|---|
| Certificates: | CE, FCC, RoHS, EAC |
|---|
| Cloud services supported: | TP-Link ID |
|---|
| Cloud system support: | TP-Link ID |
|---|
| Colour: | white |
|---|
| Communication standards: | IEEE 802.11ax, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11g, IEEE 802.11b, IEEE 802.11n |
|---|
| Configuration and management: | yes |
|---|
| Cpu clock speed: | 1.5 GHz |
|---|
| Dc output socket: | yes |
|---|
| Dc-in jack: | Yes |
|---|
| Depth: | 105 mm |
|---|
| Depth (mm): | 105 |
|---|
| Despite: | yes |
|---|
| Destiny: | 4G, Wireless, xDSL |
|---|
| Dimensions: | 105 x 105 x 167 mm |
|---|
| Dynamic dns (ddns): | Yes |
|---|
| Dynamic ip: | Yes |
|---|
| Dynamic ip address: | yes |
|---|
| Embedded processor: | yes |
|---|
| Encryption / security: | WPA, WPA3, WPA-PSK |
|---|
| Encryption and security: | WPA-Personal, WPA2-Personal, WPA3-Personal |
|---|
| Equipment: | Documentation, Ethernet cable, 2x Power supply |
|---|
| Ethernet cable: | Yes |
|---|
| Ethernet lan (rj-45) ports: | 3 |
|---|
| Ethernet lan ports (rj-45) quantity: | 3 |
|---|
| Ethernet wan: | Yes |
|---|
| Fixed ip: | yes |
|---|
| Forwarding: | yes |
|---|
| Guest access: | Yes |
|---|
| Harmonized system (hs) code: | 85171800 |
|---|
| Height: | 167 mm |
|---|
| Height (mm): | 167 |
|---|
| Lan connectors: | 3x RJ-45 |
|---|
| Leds: | Power |
|---|
| Line: | Art deco |
|---|
| Manufacturer's warranty: | 36 months |
|---|
| Maximum transmission speed: | 1201 Mbps |
|---|
| Mimo: | Yes |
|---|
| Mobile network generation: | 3G, 4G |
|---|
| Mu-mimo technology: | Yes |
|---|
| Network cable: | yes |
|---|
| Network standards and protocols: | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ax |
|---|
| Networking standards: | IEEE 802.11b, IEEE 802.11ac, IEEE 802.11g, IEEE 802.11n, IEEE 802.11a, IEEE 802.11ax |
|---|
| Number of adapters included: | 1 pc(s) |
|---|
| Number of antennas: | 4 |
|---|
| Number of devices supported: | 150 |
|---|
| Number of guest networks (2.4 ghz): | 1 |
|---|
| Number of guest networks (5 ghz): | 1 |
|---|
| Number of included products: | 1 pc |
|---|
| Number of processor cores: | 4 |
|---|
| Number of products included: | 1 pc(s) |
|---|
| Number of supported devices: | 150 |
|---|
| Operating frequency: | 2.4/5.0 GHz |
|---|
| Operating humidity range (%): | 10 - 90 |
|---|
| Operating modes: | 3G/4G, Router, Access Point |
|---|
| Operating relative humidity (h-h): | 10 - 90% |
|---|
| Operating temperature (t-t): | 0 - 40 °C |
|---|
| Operating temperature range (deg. c): | 0 - 40 |
|---|
| Permissible relative humidity: | 5 - 90% |
|---|
| Point-to-point over ethernet (pppoe): | yes |
|---|
| Point-to-point protocol over ethernet (pppoe): | Yes |
|---|
| Port forwarding: | Yes |
|---|
| Ports: | 3x RJ-45 10/100/1000 Mbps | 2x Wi-Fi antenna connector | nano-SIM card slot |
|---|
| Power: | Power |
|---|
| Power supply input current: | 0.6 A |
|---|
| Processor cores: | 4 |
|---|
| Processor frequency: | 1.5 GHz |
|---|
| Product colour: | White |
|---|
| Product depth: | 105 mm |
|---|
| Product height: | 167 mm |
|---|
| Product width: | 105 mm |
|---|
| Quality of service (qos) support: | Yes |
|---|
| Relative humidity range: | 10 - 90% |
|---|
| Reset button: | Yes |
|---|
| Security algorithms: | WPA-PSK, WPA3, WPA |
|---|
| Security measures applied: | WPA, WPA2-PSK, WPA3 |
|---|
| Sim card type: | NanoSIM |
|---|
| Smart mesh technology: | yes |
|---|
| Static ip: | Yes |
|---|
| Storage relative humidity (h-h): | 5 - 90% |
|---|
| Storage temperature (t-t): | -40 - 60 °C |
|---|
| Supported 4g networks: | 2100, 1800, 800, 2300, 900, 850, 700, 2600 MHz, 2500 |
|---|
| Supported network protocols (ipv6): | Y |
|---|
| Supported routing protocols: | Dynamic |
|---|
| Supported umts bands: | 900, 850, 2100 MHz |
|---|
| Temperature range (operation): | 0 - 40 °C |
|---|
| Temperature range (storage): | -40 - 60 °C |
|---|
| The set includes: | Power Supply, RJ45 Ethernet Cable, Quick Setup Guide, 2x SMB-SMA Antenna Connector Adapters |
|---|
| Top wi-fi standard: | Wi-Fi 6 (802.11ax) |
|---|
| Transmit power: | CE: ≤20 dBm (2.4GHz), ≤23 dBm (5GHz) |
|---|
| Transmitting power: | CE: ≤20 dBm (2.4GHz), ≤23 dBm (5GHz) |
|---|
| Umts bands supported: | 850, 900, 2100 MHz |
|---|
| Warranty: | 3 years |
|---|
| Wi-fi band: | Dual-band (2.4 GHz / 5 GHz) |
|---|
| Wi-fi frequency: | Dual-band (2.4 GHz/5 GHz) |
|---|
| Wi-fi standards: | 802.11g, Wi-Fi 4 (802.11n), 802.11a, Wi-Fi 6 (802.11ax), 802.11b, Wi-Fi 5 (802.11ac) |
|---|
| Width: | 105 mm |
|---|
| Width (mm): | 105 |
|---|
| Wireless networking: | yes |
|---|
| Wireless standards: | 5 GHz: IEEE 802.11ax/ac/n/a | 2.4 GHz: IEEE 802.11ax/n/g/b |
|---|
| Wlan data indicator (second band): | 1201 Mbit/s |
|---|
| Wlan data transfer indicator (first band): | 574 Mbit/s |
|---|
| Wlan data transfer rate (first band): | 574 Mbit/s |
|---|
| Wlan data transfer rate (second band): | 1201 Mbit/s |
|---|
