Switch mode power supply installed on TS35/7.5 or 15 DIN rail, resistant to high operating temperatures (up to 70°C)
SWITCH MODE POWER SUPPLY DRL-24V120W-1EN LYTE II
PLN 125.31
Shipping from warehouse: D4
Estimated shipping: Mon, Dec 8 - Tue, Dec 9
14 days returnUnconditional return policy
- Availability:
- moderate quantity
- Brand:
- DELTA ELECTRONICS
- Product code:
- DRL-24V120W-1EN / 5902887072772
Share this product:
Specification
| Dimensions: | 123.6 x 116.8 x 30 mm |
|---|---|
| Efficiency: | 88.5 % |
| Enclosure type: | DIN |
| Number of outputs: | 2 pcs. |
| Operating temperature / relative humidity: | -40 °C ... 70 °C / 20 ... 95 % |
| Output voltage: | 24 volts DC |
| Output voltage adjustment: | 21.6 ... 26.4 VDC |
| Power supply: | 120 watts (Printing) |
| Power supply current efficiency: | 5 A |
| Scales: | 0.45 kg |
| Security: | Short circuit overload anti-surge temperature |
| Supply voltage: | 90 ... 264 VAC |
| Type of power supply: | Pulse |
| Warranty: | 3 years |
Despite our best efforts, we cannot guarantee that the published technical data and photos do not contain inaccuracies or errors, which, however, cannot be a basis for claims.
