SSD Samsung PM9A3 3.84TB U.2 NVMe PCI 4.0 MZQL23T8HCLS-00A07 DWPD 1
This product is not available
- Availability:
- expected delivery
- Brand:
- Samsung SemiConductor
- Product code:
- MZQL23T8HCLS-00A07 /
Share this product:
Specification
| Component for: | Server/workstation |
|---|---|
| Controller type: | Samsung Elpis |
| Depth: | 3.8 mm |
| Dwpd: | 1 |
| End-to-end data protection: | Yes |
| Hardware encryption: | Yes |
| Harmonized system (hs) code: | 84717070 |
| Height: | 22 mm |
| Interface: | PCI Express 4.0 |
| Mean time between failures (mtbf): | 2000000 h |
| Memory type: | V-NAND TLC |
| Nvme: | Yes |
| Nvme version: | 1.4 |
| Operating temperature (t-t): | 0 - 70 °C |
| Operating voltage: | 12 V |
| Package type: | OEM |
| Power consumption (max): | 3.5 W |
| Power consumption (read): | 11 W |
| Power consumption (write): | 13.5 W |
| Product series: | PM9A3 |
| Random read (4kb): | 1000000 IOPS |
| Random write (4kb): | 180000 IOPS |
| Read speed: | 6900 MB/s |
| S.m.a.r.t. support: | Yes |
| Security algorithms: | 256-bit AES |
| Sequential read speed (as ssd): | 6900 MB/s |
| Sequential write speed (as ssd): | 4100 MB/s |
| Ssd capacity: | 3.84 TB |
| Ssd form factor: | U.2 |
| Trim support: | Yes |
| Weight: | 90 g |
| Width: | 110.2 mm |
| Write speed: | 4100 MB/s |
