Shuttle XPC slim Barebone XH510G - S1200, Intel H510, 1xDP, 1xHDMI, 1x PCI-E 16X, 1x LAN, 1x 2.5", 2x M.2, 24/7 permanent operation
This product is not available
- Availability:
- expected delivery
- Brand:
- Shuttle
- Product code:
- XH510G / 0887993005041
Share this product:
Specification
| Ac adapter included: | Yes |
|---|---|
| Ac adapter output current: | 9.23 A |
| Ac adapter output voltage: | 19.5 V |
| Ac input frequency: | 50 - 60 Hz |
| Ac input voltage: | 100 - 240 V |
| Audio output channels: | 7.1 channels |
| Built-in processor: | No |
| Built-in speaker(s): | No |
| Cable lock slot: | Yes |
| Cable lock slot type: | Kensington |
| Compatible processor series: | Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium® Gold, Intel® Core™ i5, Intel® Celeron®, Intel® Core™ i3 |
| Cooling type: | Active |
| Country of origin: | China |
| Dc-in jack: | Yes |
| Depth: | 200 mm |
| Displayport version: | 1.4 |
| Displayports quantity: | 1 |
| Drivers included: | Yes |
| Ethernet lan: | Yes |
| Ethernet lan (rj-45) ports: | 1 |
| Graphics card family: | Intel |
| Harmonized system (hs) code: | 84733080 |
| Hdmi ports quantity: | 1 |
| Hdmi version: | 2.0a |
| Headphone outputs: | 1 |
| Height: | 78.5 mm |
| Lan controller: | Intel® I219-LM |
| Led indicators: | HDD, Power |
| Linux operating systems supported: | Yes |
| Maximum internal memory: | 64 GB |
| Memory channels: | Dual-channel |
| Memory slots type: | SO-DIMM |
| Microphone in: | Yes |
| Motherboard chipset: | Intel H510 |
| Non-ecc: | Yes |
| Number of memory slots: | 2 |
| Number of processors supported: | 1 |
| Number of storage drives supported: | 2 |
| Nvme: | Yes |
| On-board graphics card: | Yes |
| On/off switch: | Yes |
| Operating relative humidity (h-h): | 10 - 90% |
| Operating system installed: | No |
| Operating temperature (t-t): | 0 - 50 °C |
| Pci express slots version: | 4.0 |
| Pci express x16 slots: | 1 |
| Power cord included: | Yes |
| Power supply: | 180 W |
| Power supply type: | External AC adapter |
| Processor socket: | LGA 1200 (Socket H5) |
| Product colour: | Black |
| Product type: | PC barebone |
| Quick start guide: | Yes |
| Storage drive interface: | M.2, Serial ATA III |
| Storage drive sizes supported: | M.2, 2.5 |
| Supported memory clock speeds: | 2933, 3200 MHz, 2666 |
| Supported memory types: | DDR4-SDRAM |
| Supported storage drive types: | HDD & SSD |
| Trusted platform module (tpm): | Yes |
| Usb 2.0 ports quantity: | 4 |
| Usb 3.2 gen 1 (3.1 gen 1) type-a ports quantity: | 4 |
| Vesa mounting: | Yes |
| Weight: | 3.2 kg |
| Wi-fi: | No |
| Width: | 250 mm |
| Windows operating systems supported: | Windows 11, Windows 10 |
Despite our best efforts, we cannot guarantee that the published technical data and photos do not contain inaccuracies or errors, which, however, cannot be a basis for claims.
