Shuttle XPC slim Barebone DL30N, Intel N100, 1x DDR5, 2x LAN (2x 2.5Gbit), 2xCOM,1xHDMI,1xDP, 1x VGA, fanless, 24/7 permanent operation
PLN 1,259.86
Shipping from warehouse: A3
Estimated shipping: Fri, Dec 12 - Mon, Dec 15
14 days returnUnconditional return policy
- Availability:
- large quantity
- Brand:
- Shuttle
- Product code:
- DL30N / 0887993006093
Share this product:
Specification
| Ac adapter included: | Yes |
|---|---|
| Ac adapter output current: | 3.42 A |
| Ac adapter output voltage: | 19 V |
| Ac input frequency: | 50/60 Hz |
| Ac input voltage: | 100 - 240 V |
| Audio chip: | Realtek ALC888S |
| Bios type: | UEFI AMI |
| Built-in processor: | Yes |
| Built-in speaker(s): | No |
| Cable lock slot: | Yes |
| Cable lock slot type: | Kensington |
| Card reader integrated: | No |
| Chassis type: | 1.35L sized PC |
| Compliance certificates: | Federal Communications Commission (FCC), VCCI, RoHS, CE, UKCA, RCM, BSMI |
| Cooling type: | Passive |
| Dc-in jack: | Yes |
| Depth: | 190 mm |
| Discrete graphics card model: | Not available |
| Displayport version: | 1.4a |
| Displayports quantity: | 1 |
| Drivers included: | Yes |
| Ecc: | No |
| Ecc supported by processor: | No |
| Ethernet lan: | Yes |
| Ethernet lan (rj-45) ports: | 2 |
| Graphics card family: | Intel |
| Harmonized system (hs) code: | 84733080 |
| Hdmi ports quantity: | 1 |
| Hdmi version: | 2.0b |
| Headphone outputs: | 1 |
| Height: | 43 mm |
| Housing material: | Steel |
| Lan controller: | Intel I226-LM |
| Led indicators: | Power, HDD |
| Linux operating systems supported: | Yes |
| Maximum internal memory: | 16 GB |
| Maximum resolution: | 4096 x 2160 pixels |
| Memory channels: | Single-channel |
| Memory slots type: | SO-DIMM |
| Memory voltage: | 1.1 V |
| Microphone in: | Yes |
| Non-ecc: | Yes |
| Number of displays supported: | 3 |
| Number of memory slots: | 1 |
| Number of power supply units: | 1 |
| Number of processors supported: | 1 |
| Number of storage drives supported: | 2 |
| Nvme: | Yes |
| On-board graphics card: | Yes |
| On-board graphics card model: | Intel® UHD Graphics |
| On/off switch: | Yes |
| Operating relative humidity (h-h): | 10 - 90% |
| Operating system installed: | No |
| Operating temperature (t-t): | 0 - 40 °C |
| Package weight: | 2.1 kg |
| Panel mounting interface: | 100 x 75 |
| Power cord included: | Yes |
| Power supply: | 65 W |
| Power supply type: | External AC adapter |
| Processor boost frequency: | 3.4 GHz |
| Processor cache: | 6 MB |
| Processor cores: | 4 |
| Processor manufacturer: | Intel |
| Processor model: | N100 |
| Processor threads: | 4 |
| Product colour: | Black |
| Product type: | Mini PC barebone |
| Quick start guide: | Yes |
| Serial ports quantity: | 2 |
| Storage drive interface: | PCI Express, Serial ATA III |
| Storage drive sizes supported: | M.2, 2.5 |
| Supported memory clock speeds: | 4800 MHz |
| Supported memory types: | DDR5-SDRAM |
| Supported storage drive types: | HDD & SSD |
| Sustainability certificates: | ENERGY STAR, ErP |
| Sustainability compliance: | Yes |
| Thermal design power (tdp): | 6 W |
| Trusted platform module (tpm): | Yes |
| Trusted platform module (tpm) version: | 2.0 |
| Usb 3.2 gen 1 (3.1 gen 1) type-a ports quantity: | 8 |
| Vesa mounting: | Yes |
| Vga (d-sub) ports quantity: | 1 |
| Weight: | 800 g |
| Wi-fi: | No |
| Width: | 165 mm |
| Windows operating systems supported: | Windows 11 x64, Windows 10 |
