| Alarm signaling:: | LED, Signal for alarm control panel |
|---|---|
| Colour:: | white |
| Detection:: | Glass break sensor |
| Dimensions:: | 24 x 110 x 27 mm |
| Environmental class:: | II |
| Manufacturer / brand:: | SATEL |
| Operating temperature:: | -10 °C ... 55 °C |
| Permissible load on relay contacts (resistive):: | 40 mA / 16 V DC |
| Power:: | 12 VDC / 10 mA |
| Range:: | Max. 6 m |
| Scales:: | 0.04 kg |
| Selected features:: | plain, tempered and laminated glass break detection advanced microprocessor dual-track signal analysis smooth sensitivity adjustment |
| Warranty:: | 2 years |
The sensor signals an alarm if it registers a low-frequency signal (impact sound) and a high-frequency signal (broken glass sound)A low-frequency sound wave caused by an impact causes the sensor to start analyzing the high-frequency channel
The microphone recording the sound of a shock wave is indicated by the flashing of the LEDHigh-frequency channel analysis takes 4 secondsIf a high-frequency sound occurs during this time, i.e. the sound of broken glass, the sensor triggers an alarm
