Technical information:
- Controlled by rotary potentiometer
- PUSH-PUSH switch type, stair switch type
- Control power element: triac
- Possibility of working in a staircase-cross system with a stair switch
Security:
- Short circuit with conventional fuse
- Temperature - after exceeding 125 degrees C on the elements inside the housing, the dimmer is turned off.
Technical data:
- Supply voltage: 230V 50 Hz
- Output power: 40 – 400W
- Complies with EU-EN 55015 (interference) -EN 60669-2-1 (safety of use)
- Dimensions: 71 x 71 x 29 mm
- For canned mounting: avg. 60.
Workload operation:
- Conventional incandescent
- Halogen 230 V
- Halogen low voltage 12 V (with toroidal transformers)
