External card and key ring reader designed to work in the access control and building automation system RACS 5Standard MIFARE DESFire/Plus
ROGER MCT12M-DES-IO PROXIMITY READER
PLN 758.16
Shipping from warehouse: D4
Estimated shipping: Thu, Oct 30 - Mon, Nov 3
14 days returnUnconditional return policy
- Availability:
- moderate quantity
- Brand:
- ROGER
- Product code:
- MCT12M-DES-IO / 5907608961113
Share this product:
Specification
| Average current consumption:: | ~ 50 mA |
|---|---|
| Card reading range:: | Max. 7 cm |
| Card support:: | MIFARE Ultralight, MIFARE Classic, MIFARE Plus, MIFARE DESFire |
| Communication:: | RS-485, RACS 5 (Roger) |
| Cooperation:: | RACS 5 (Roger) |
| Dimensions:: | 152 x 46 x 23 mm |
| Manufacturer / brand:: | ROGER |
| Operating temperature:: | -25 °C ... 60 °C |
| Permissible relative humidity:: | 10 ... 95 % (non-condensing) |
| Power:: | 10 ... 15 VDC |
| Scales:: | 0.15 kg |
| Sealing:: | IP65 |
| Selected features:: | Tamper protection (detection of detachment from the ground and opening of the housing) LED signaling Sound signal Built-in I/O lines 3 inputs 1 Relay output : REL1 - NO/NC, 30 V AC/DC / 1.5 A Two transistor outputs : IO1, IO2 - Open collector (OC) type, max. 15 VDC / 1 A |
| Warranty:: | 3 years |
