AC type residual current circuit breaker with rated residual current IΔn = 30mAThe LE-411509 switch is designed for mounting on the TS-35 DIN rail
RESIDUAL CURRENT CIRCUIT BREAKER LE-411509 SINGLE PHASE, TYPE AC 30 mA 25 A LEGRAND
PLN 158.14
Shipping from warehouse: D4
Estimated shipping: Tue, Oct 28 - Fri, Oct 31
14 days returnUnconditional return policy
- Availability:
- moderate quantity
- Brand:
- Legrand
- Product code:
- LE-411509 / 3414970352408
Share this product:
Specification
| Case:: | Plastic, DIN rail mounting, TS-35 |
|---|---|
| Connector type:: | screw terminals |
| Current:: | 25 A |
| Device type:: | Residual current circuit breaker, Single phase, Type AC |
| Dimensions:: | 36 x 83 x 75 mm |
| Manufacturer / brand:: | LEGRAND |
| Number of poles:: | 2 |
| Rated differential current:: | 30 mA |
| Rated short-circuit switching capacity:: | 10000 A |
| Scales:: | 0.186 kg |
| Selected features:: | Can be equipped with auxiliary contacts, triggers and drives from the DX3 series Provided space for a sheet of paper with a description Can be connected using comb or stick rails |
| Voltage:: | 230 V AC / 50 Hz |
| Warranty:: | 2 years |
| Width in modules 17.5 mm:: | 2 |
