Residual current circuit breaker 4P 40A 0,03A type AC P304 RX3 402063
PLN 175.34
Shipping from warehouse: D4
Estimated shipping: Tue, Oct 28 - Fri, Oct 31
14 days returnUnconditional return policy
- Availability:
- moderate quantity
- Brand:
- Legrand
- Product code:
- 402063 / 3245064020633
Share this product:
Specification
| Built-in depth [mm]: | 44 |
|---|---|
| Current surge resistance [ka]: | 0.2500 |
| Degree of protection (ip): | IP2X |
| Enclosure dimension (according to din 43880): | 4 |
| Mounting method: | DIN rail |
| Number of poles: | 4 |
| Possibility of additional equipment: | Yes |
| Rated current [a]: | 40 |
| Rated differential current [a]: | 0.0300 |
| Rated short-circuit capacity [ka]: | 10 |
| Rated voltage [v]: | 400 |
| Selective protection: | No |
| Sensitivity: | AC |
| Short-delay triggering: | No |
| Width expressed by the number of modules: | 4 |
