Booster converter moduleThe PZU-4810-D2 device converts the input voltage to 8V ... 48V DC
PZU-4810-D2 DC/DC INVERTER MODULE
€70.10
Shipping from warehouse: D4
Estimated shipping: Mon, Oct 27 - Thu, Oct 30
14 days returnUnconditional return policy
- Availability:
- moderate quantity
- Brand:
- Delta
- Product code:
- PZU-4810-D2 / 5902887016479
Share this product:
Specification
| Destiny: | to power cameras to power PoE cameras to power cameras with thermostat |
|---|---|
| Dimensions: | 37 x 97 x 58 mm |
| Minimum voltage difference between output and input.: | 0 volts |
| Number of inputs: | 1 |
| Number of outputs: | 1 |
| Output: | 5 A (max) |
| Output voltage: | 8 ... 48 VDC |
| Output voltage adjustment: | Adjustable with precise multiturn potentiometer (27 rpm) |
| Power: | 100 W (max) 48 W (continuous) |
| Producer / brand: | DELTA |
| Scales: | 0.12 kg |
| Security: | Short circuit suppression - Fuse fuse Thermal > 80 °C Reverse connection |
| Selected features: | DIN rail mounting, TS-35 LED indication - Input voltage, Output voltage |
| Supply voltage: | 8 ... 36 VDC |
| Type: | Voltage boost, DC/DC |
| Warranty: | 3 years |
Despite our best efforts, we cannot guarantee that the published technical data and photos do not contain inaccuracies or errors, which, however, cannot be a basis for claims.
