PLANET MGSW-24160F network switch Managed L2+ Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) 1U Blue
€730.11
Shipping from warehouse: E12
Estimated shipping: Tue, Jun 16 - Fri, Jun 19
14 days returnUnconditional return policy
- Availability:
- large quantity
- Brand:
- PLANET
- Product code:
- MGSW-24160F / 4711213688522
Share this product:
Specification
| 10g support: | N |
|---|---|
| Ac adapter included: | Y |
| Ac input frequency: | 50 - 60 Hz |
| Ac input voltage: | 100 - 240 V |
| Access control list (acl): | Y |
| Admin-edge port: | Y |
| Arp inspection: | Y |
| Auto mdi/mdi-x: | Y |
| Auto-edge port: | Y |
| Auto-negotiation: | Y |
| Basic switching rj-45 ethernet ports quantity: | 8 |
| Basic switching rj-45 ethernet ports type: | Gigabit Ethernet (10/100/1000) |
| Bpdu filtering/protection: | Y |
| Cables included: | RS-232 |
| Compatible memory cards: | Not supported |
| Console port: | RS-232 |
| Copper ethernet cabling technology: | 1000BASE-T, 100BASE-TX, 10BASE-T, 100BASE-T, 100BASE-FX, 1000BASE-TX |
| Depth: | 200 mm |
| Dhcp features: | DHCP client, DHCP server |
| Fiber ethernet cabling technology: | 1000BASE-X |
| Fiber type: | Multi-mode |
| Flow control support: | Y |
| Form factor: | 1U |
| Full duplex: | Y |
| Harmonized system (hs) code: | 85176990 |
| Height: | 44.5 mm |
| Igmp snooping: | Y |
| Ip routing: | Y |
| Ip-mac-port binding: | Y |
| Jumbo frames: | 10000 |
| Jumbo frames support: | Y |
| Led indicators: | Y |
| Link aggregation: | Y |
| Loop protection: | Y |
| Mac address auto-aging supported: | Y |
| Mac address auto-learning supported: | Y |
| Mac address filtering: | Y |
| Mac address table: | 16000 entries |
| Multicast support: | Y |
| Networking standards: | IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.1w, IEEE 802.1D, IEEE 802.3z, IEEE 802.1Q, IEEE 802.3x, IEEE 802.1s, IEEE 802.1x, IEEE 802.1ab |
| Number of fans: | 2 fan(s) |
| Number of multicast groups filtered: | 255 |
| Number of queues: | 8 |
| Number of trunks: | 24 |
| On/off switch: | Y |
| Operating relative humidity (h-h): | 5 - 95% |
| Operating temperature (t-t): | 0 - 60 °C |
| Port mirroring: | Y |
| Power consumption (max): | 38 W |
| Power over ethernet (poe): | Y |
| Power over ethernet (poe) ports quantity: | 8 |
| Power over ethernet plus (poe+) ports quantity: | 8 |
| Power supply included: | N |
| Product colour: | Blue |
| Quality of service (qos) support: | Y |
| Quick start guide: | Y |
| Rack mount kit: | Y |
| Rack mounting: | Y |
| Reset button: | Y |
| Rubber feet: | Y |
| Security algorithms: | SNMP, SSH, SSL/TLS |
| Sfp module slots quantity: | 16 |
| Spanning tree protocol: | Y |
| Ssh/ssl support: | Y |
| Stackable: | Y |
| Storage relative humidity (h-h): | 5 - 95% |
| Storage temperature (t-t): | -10 - 70 °C |
| Store-and-forward: | Y |
| Switch layer: | L2+ |
| Switch type: | Managed |
| Switching capacity: | 48 Gbit/s |
| System event log: | Y |
| Terminal block included: | Y |
| Terminal block port: | Y |
| Throughput: | 35.6 Mpps |
| Traffic classification: | Y |
| Traffic shaping: | Y |
| Transmission distance (max): | 120 km |
| Virtual lan features: | Port-based VLAN, Private VLAN, Protocol-based VLAN |
| Vlan support: | Y |
| Web-based management: | Y |
| Weight: | 3 kg |
| Width: | 440 mm |
