| Adjustable traffic routes: | 8 |
|---|
| Alarm input/output: | Y |
|---|
| Alarm inputs / outputs: | 2 / 1 |
|---|
| Aperture: | F1.6 - F4.0 |
|---|
| Audio: | External microphone input Audio output Support two-way audio Sound detection |
|---|
| Back light compensation (blc): | Y |
|---|
| Bit rate: | H.264: 3 kbps–20480 kbps, H.265: 3 kbps–20480 kbps |
|---|
| Bit rate control: | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
|---|
| Bluetooth: | N |
|---|
| Built-in hdd: | N |
|---|
| Camera pan control: | Y |
|---|
| Camera shutter speed: | 1/1 - 1/30000 s |
|---|
| Camera shutter type: | Electronic |
|---|
| Camera tilt control: | Y |
|---|
| Case: | Speed Dome, Metal + Plastic |
|---|
| Closest focusing distance: | 0.8 m |
|---|
| Colour: | White + Black |
|---|
| Compatible memory cards: | MicroSD (TransFlash) |
|---|
| Connectivity technology: | Wired |
|---|
| Day/night mode: | Y |
|---|
| Default administrator login / password: | admin / -Administrator password must be set on first run |
|---|
| Default ip address: | 192.168.1.108 |
|---|
| Detect distance: | 2,124 m |
|---|
| Diameter: | 19 cm |
|---|
| Digital zoom: | 16x |
|---|
| Dimensions: | 190 x 415 x 268 mm (with bracket) |
|---|
| Ethernet lan: | Y |
|---|
| Ethernet lan (rj-45) ports: | 1 |
|---|
| Focal length range: | 4.8 - 154 mm |
|---|
| Form factor: | Dome |
|---|
| Frame rate: | 30 fps |
|---|
| Gain control type: | Auto/Manual |
|---|
| Height: | 332 mm |
|---|
| Highlight compensation (hlc): | Y |
|---|
| Horizontal rotation range: | 360° - continuous |
|---|
| Identify distance: | 212 m |
|---|
| Ik code: | IK10 |
|---|
| Image compression method: | H.265+ / H.265 / H.264+ / H.264B / H.264M / H.264H / MJPEG |
|---|
| International protection (ip) code: | IP67 |
|---|
| Ir illuminator range: | 150 m |
|---|
| Led type: | IR |
|---|
| Lens viewing angle, diagonal: | 63.71 - 2.71° |
|---|
| Lens viewing angle, horizontal: | 55.81 - 2.37° |
|---|
| Lens viewing angle, vertical: | 31.92 - 1.34° |
|---|
| Main stream transmission speed: | 25 fps @ 4 Mpx |
|---|
| Management software: | Smart Player, Smart PSS, DSS, Easy4ip |
|---|
| Max. number of on-line users: | 20 |
|---|
| Maximum memory card size: | 256 GB |
|---|
| Maximum resolution: | 2560 x 1440 pixels |
|---|
| Memory card slot: | Micro SD card support up to 512GB (local recording possible) |
|---|
| Mobile app access port: | 37777 |
|---|
| Mobile operating systems supported: | Android, iOS |
|---|
| Mobile phone access: | Port: 37777 or cloud access (P2P) Android: Free DMSS app iOS (iPhone): Free DMSS app |
|---|
| Mounting type: | Ceiling |
|---|
| Multicast support: | Y |
|---|
| Network interface: | 10/100 Base-T (RJ-45) |
|---|
| Network protocols: | HTTP, HTTPS, IPv4/IPv6, RTSP, UDP, SMTP, NTP, DHCP, DNS, DDNS, IEEE 802.1x, QoS, FTP, UPnP, ICMP, SNMP, SNMPv1/v2c/v3(MIB-2), IGMP, ARP, RTCP, RTP, PPPoE, RTMP, TCP |
|---|
| Night vision: | Y |
|---|
| Night vision distance: | 150 m |
|---|
| Noise reduction: | Y |
|---|
| Noise reduction technology: | 2D noise reduction, 3D noise reduction |
|---|
| Number of cameras: | 1 |
|---|
| Number of lenses: | 1 |
|---|
| Number of presets: | 300 |
|---|
| Number of users: | 20 user(s) |
|---|
| Objective: | 4.8 ... 154 mm |
|---|
| Onvif: | 20.06 |
|---|
| Operating relative humidity (h-h): | 0 - 95% |
|---|
| Operating temperature: | -40 °C ... 70 °C |
|---|
| Operating temperature (t-t): | -40 - 70 °C |
|---|
| Optical sensor size: | 25.4 / 2.8 mm (1 / 2.8") |
|---|
| Optical zoom: | 32x |
|---|
| Package weight: | 8 kg |
|---|
| Pan range: | 0 - 360° |
|---|
| Pan speed: | 400 °/sec |
|---|
| Pc app access ports: | 37777 |
|---|
| Placement supported: | Indoor & outdoor |
|---|
| Port onvif: | 80 |
|---|
| Power: | PoE (802.3at), 24 V AC / 2.5 A (power adapter included) |
|---|
| Power consumption: | .max. 22 watts |
|---|
| Power consumption (max): | 22 W |
|---|
| Power source type: | DC, PoE |
|---|
| Privacy masking: | Y |
|---|
| Producer / brand: | DAHUA |
|---|
| Product colour: | White |
|---|
| Progressive scan: | Y |
|---|
| Ram capacity: | 1 GB |
|---|
| Recognize distance: | 425 m |
|---|
| Region of interest (roi) encoding: | Y |
|---|
| Resolution: | 2560 x 1440 - 3.7 Mpx, 2048 x 1536 - 3 Mpx, 1920 x 1080 - 1080p, 1280 x 960 - 1.3 Mpx, 1280 x 720 720p |
|---|
| Rom capacity: | 4096 MB |
|---|
| Rotational speed (manual control): | 0.1 °/s ... 300°/s (horizontal) 0.1°/s ... 200°/s (vertical) |
|---|
| Rotational speed at presets: | 400°/s (horizontal), 300°/s (vertical) |
|---|
| Rtsp url: | rtsp://admin:password o@192.168.1.108:554/cam/realmonitor?channel=1&subtype=0 - Main streamrtsp://admin:password o@192.168.1.108:554/cam/realmonitor?channel=1&subtype=1 - Auxiliary stream |
|---|
| Scales: | 5.3 kg (with handle) |
|---|
| Sealing: | IP67 |
|---|
| Selected features: | Intelligent object tracking WDR - 120 dB - Wide dynamic range of 2D-DNR, 3D-DNR - Digital image noise reduction EIS - Electronic image stabilization ROI - improving the quality of selected parts of the image F-DNR (Defog) - Noise reduction associated with precipitation BLC/HLC - compensation of background light / strong light Motion detection Privacy zones - max. 24 Day/Night Mode ICR - Mechanical IR Filter WB - White Balance (ATW/AWB/Manual/Indoor/External) AGC - Automatic image gain adjustment Sharpness - Sharpen image contours SMD PLUS - search for an object classified as: human, motor vehicle, non-motor vehicle - metadata support IVS analysis : line crossing, intrusion, abandoned/missing object, gathering detection, area wandering detection, face detection Filtering false alarms based on person and vehicle recognition (line crossing, intrusion) |
|---|
| Sensor size: | 4 MP |
|---|
| Sensor type: | CMOS |
|---|
| Standard: | TCP/IP |
|---|
| Supported graphics resolutions: | 2048 x 1536 (QXGA), 704 x 576, 2560 x 1440, 352 x 288, 1280 x 720, 704 x 480, 352 x 240, 1920 × 1080 |
|---|
| Supported languages: | Polish, Czech, English, Spanish, French, Dutch, German, Portuguese, Russian, Italian |
|---|
| Tilt angle range: | -15 - 90° |
|---|
| Tilt speed: | 300 °/sec |
|---|
| Total megapixels: | 4 MP |
|---|
| Transducer: | 1/2.8" STARVIS™ CMOS |
|---|
| Type: | IP security camera |
|---|
| Vandal-resistant: | IK10 |
|---|
| Vertical rotation range: | -15 ° ... 90 ° |
|---|
| Video compression formats: | H.265, H.264H, H.264B, H.265+, H.264+, M-JPEG |
|---|
| Video streaming: | Y |
|---|
| Viewing angle: | 56 ° ... 2.4 ° (manufacturer's data) 52 ° ... 2.8° (our tests) |
|---|
| Warranty: | 3 years |
|---|
| Watching the distance: | 839 m |
|---|
| Web access ports: | 80, 37777 |
|---|
| Web server: | Built-in |
|---|
| Weight: | 4.7 kg |
|---|
| White balance: | Indoor, Outdoor, Natural, Street lamp, Auto, Manual, Sodium lamp |
|---|
| Wi-fi: | N |
|---|
| Wide dynamic range (wdr): | Y |
|---|
| Zoom capability: | Y |
|---|
