| Audio: | Built-in Microphone External Microphone Input Audio Output Support Two-way Audio Detection Sound Detection |
|---|
| Bitrate: | 32 ... 16384 Kb/s |
|---|
| Case: | Speed Dome, Metal |
|---|
| Colour: | White + Black |
|---|
| Default administrator login / password: | admin / -Administrator password must be set on first run |
|---|
| Default ip address: | 192.168.1.64 |
|---|
| Digital zoom: | x 16 |
|---|
| Dimensions: | Ø 131 x 102 mm |
|---|
| Horizontal rotation range: | 355 ° - The rotation of the head is limited by the limit switch |
|---|
| Image compression method: | H.265+ H.265 / H.264+ / H.264 / MJPEG |
|---|
| Ir illuminator range: | 20 m |
|---|
| Main stream transmission speed: | 25 fps @ 1080p |
|---|
| Max. number of on-line users: | 20 |
|---|
| Memory card slot: | Micro SD card support up to 256GB (local recording possible) |
|---|
| Mobile app access port: | 8000 |
|---|
| Mobile phone access: | Port: 8000 or cloud access (P2P) Android: Free Hik-Connect app iOS: Free Hik-Connect app |
|---|
| Network interface: | 10/100 Base-T (RJ-45) |
|---|
| Network protocols: | IPv4/IPv6, HTTP, HTTPS, IEEE 802.1x, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour, WebSocket, WebSockets |
|---|
| Number of presets: | 300 |
|---|
| Objective: | 2.8 ... 12 mm |
|---|
| Operating temperature: | -20 °C ... 60 °C |
|---|
| Optical zoom: | x 4 |
|---|
| Pc app access ports: | Port: 8000 or access via cloud (P2P) - iVMS-4200 application |
|---|
| Port onvif: | 80 |
|---|
| Power: | PoE (802.3af), 12 V DC / 770 mA |
|---|
| Power consumption: | ≤ 9.2 watts |
|---|
| Producer / brand: | Hikvision |
|---|
| Resolution: | 1920 x 1080 - 1080p1280 x 960 - 1.3 MP x 7280 x 720 - 720p |
|---|
| Rotational speed (manual control): | 0.1 °/s ... 100 °/s (horizontal)0.1 °/s ... 100 °/s (vertical) |
|---|
| Rotational speed at presets: | 100°/s (horizontal) 100°/s (vertical) |
|---|
| Rtsp url: | Main streamrtsp://user:password o@192.168.1.64:554/Streaming/Channels/101/ Secondary streamrtsp://user:password o@192.168.1.64:554/Streaming/Channels/102/ |
|---|
| Sap code: | 327000658 |
|---|
| Scales: | 0.62 kg |
|---|
| Scanning system: | Progressive |
|---|
| Sealing: | IP66 |
|---|
| Selected features: | WDR - 120 dB - Wide dynamic range EIS - Electronic image stabilization 3D-DNR - Digital noise reduction in the image ROI - improving the quality of selected parts of the image F-DNR (Defog) - Reduction of noise associated with precipitation NAS support - Network Attached Storage - allows you to connect memory resources directly to the computer network ANR - recording the image on the card in the absence of communication with the recorder (network failure) and subsequent BLC/HLC synchronization - Background Light / Strong Light Compensation ICR - Mechanical IR Filter Day/Night Mode Mirror - Image mirroring Motion detection Configurable privacy zones - 24 Configurable: brightness, contrast, saturation Sharpness - Sharpen image contours Intelligent image analysis : intrusion, line crossing, abandoned/missing object, area entry detection/area exit, face detection |
|---|
| Sensor size: | 2.1 MP |
|---|
| Standard: | TCP/IP |
|---|
| Supported languages: | Polish, Bulgarian, Croatian, Czech, Danish, Dutch, English, Estonian, Finnish, French, German, Greek, Hungarian, Italian, Latvian, Lithuanian, Norwegian, Portuguese, Romanian, Russian, Serbian, Slovak, Slovenian, Spanish, Swedish, Turkish, Vietnamese |
|---|
| Transducer: | 1/2.8" Progressive Scan CMOS |
|---|
| Vandal-resistant: | IK10 |
|---|
| Vertical rotation range: | 0 ° ... 90 ° |
|---|
| Viewing angle: | 101 ° ... 33 ° (manufacturer data) |
|---|
| Warranty: | 3 years |
|---|
| Web access ports: | 80 |
|---|
| Web server: | Built-in, NVR compliant |
|---|
