ONLINE USV-Systeme ZINTO 1500 uninterruptible power supply (UPS) Line-Interactive 1.5 kVA 1350 W 8 AC outlet(s)
This product is not available
- Availability:
- expected delivery
- Brand:
- Bachmann
- Product code:
- Z1500 / 4026908003635
Share this product:
Specification
| Ac outlet types: | C13 coupler |
|---|---|
| Ac outlets quantity: | 8 AC outlet(s) |
| Battery capacity: | 9 Ah |
| Battery voltage: | 48 V |
| Cables included: | Power load cable, USB cable |
| Cold start: | Yes |
| Depth: | 512 mm |
| Display type: | LCD |
| Efficiency: | 97% |
| Ethernet lan (rj-45) ports: | 2 |
| Form factor: | Rackmount/Tower |
| Harmonized system (hs) code: | 85078000 |
| Height: | 88 mm |
| Hot-swap battery: | Yes |
| Input frequency: | 50/60 Hz |
| Input operation voltage (max): | 274 V |
| Input operation voltage (min): | 176 V |
| International protection (ip) code: | IP20 |
| Maximum current: | 11 A |
| Mean time between failures (mtbf): | 50000 h |
| Noise level: | 45 dB |
| Operating relative humidity (h-h): | 0 - 90% |
| Operating temperature (t-t): | 0 - 40 °C |
| Output frequency regulation: | 50/60 Hz |
| Output operation voltage (max): | 240 V |
| Output operation voltage (min): | 208 V |
| Output power: | 1350 W |
| Output power capacity: | 1.5 kVA |
| Output voltage regulation: | +3 - -3% |
| Power plug: | C14 coupler |
| Product colour: | Black |
| Quick installation guide: | Yes |
| Rack capacity: | 2U |
| Rack mount kit: | Yes |
| Rs-232 ports: | 1 |
| Safety: | EN62040-1 |
| Serial interface: | Yes |
| Serial interface type: | RS-232 |
| Typical backup time at full load: | 10 min |
| Typical backup time at half load: | 23 min |
| Ups topology: | Line-Interactive |
| Usb 2.0 ports quantity: | 1 |
| Usb port: | Yes |
| Weight: | 21 kg |
| Width: | 438 mm |
Despite our best efforts, we cannot guarantee that the published technical data and photos do not contain inaccuracies or errors, which, however, cannot be a basis for claims.
