LevelOne GEU-0523 network switch Unmanaged Gigabit Ethernet 10/100/1000) Blac
This product is not available
- Availability:
- expected delivery
- Product code:
- GEU-0523 / 4015867222256
Share this product:
Specification
| 10g support: | No |
|---|---|
| Ac adapter included: | Yes |
| Basic switching rj-45 ethernet ports quantity: | 5 |
| Basic switching rj-45 ethernet ports type: | Gigabit Ethernet (10/100/1000) |
| Built-in processor: | Yes |
| Country of origin: | China |
| Dc input voltage: | 5 V |
| Depth: | 72 mm |
| Flash memory: | 1024 MB |
| Gigabit ethernet (copper) ports quantity: | 5 |
| Harmonized system (hs) code: | 85176990 |
| Height: | 24 mm |
| Housing material: | Metal |
| Input current: | 0.5 A |
| Jumbo frames: | 9000 |
| Jumbo frames support: | Yes |
| Led indicators: | Yes |
| Mac address auto-aging supported: | Yes |
| Mac address auto-learning supported: | Yes |
| Mac address table: | 2000 entries |
| Manual: | Yes |
| Networking standards: | IEEE 802.3az |
| Operating relative humidity (h-h): | 10 - 90% |
| Operating temperature (t-t): | 0 - 40 °C |
| Package depth: | 80 mm |
| Package height: | 80 mm |
| Package weight: | 290 g |
| Package width: | 138 mm |
| Packet forwarding rate (1 gbps): | 1488000 pps |
| Power over ethernet (poe): | No |
| Power supply included: | No |
| Processor model: | MT7530D |
| Product colour: | Black |
| Quick start guide: | Yes |
| Rack mounting: | No |
| Storage relative humidity (h-h): | 5 - 90% |
| Storage temperature (t-t): | -40 - 70 °C |
| Switch type: | Unmanaged |
| Switching capacity: | 10 Gbit/s |
| Transmission method: | Store- froward |
| Wall mountable: | Yes |
| Weight: | 174 g |
| Width: | 124 mm |
Despite our best efforts, we cannot guarantee that the published technical data and photos do not contain inaccuracies or errors, which, however, cannot be a basis for claims.
