NVR301-16X is a professional device used in IP CCTV systems
IP NVR301-16X (16 CHANNELS) UNIVIEW
This product is not available
- Availability:
- expected delivery
- Brand:
- Uniview
- Product code:
- NVR301-16X / 5902887074448
Share this product:
Specification
| Archiving on external media: | Archiving to a USB drive (pendrive, external drive) |
|---|---|
| Audio inputs: | 1 pc CINCH |
| Audio outputs: | 1 pc CINCH |
| Audio support: | 16 Channels - Audio from cameras |
| Bitrate: | .max. 64 Mbps |
| Country of origin: | China |
| Default administrator login / password: | admin / 123456 |
| Default ip address: | DHCP or 192.168.1.30 |
| Dimensions: | 260 x 247 x 47 mm |
| Image compression method: | Ultra 265 / H.265 / H.264 |
| Mobile app access port: | 80 |
| Mobile phone access: | Port: 80 or cloud access (P2P) Android: Free EZView app iOS (iPhone): Free EZView app |
| Network features: | Full support via network, Remote copying of recordings, Built-in web servermax. 128 users on-lineSoftware update via cloud |
| Network protocols: | TCP/IP, P2P, UPnP, NTP, DHCP, PPPoE, HTTP, HTTPS, DNS, DDNS, SNMP, SMTP, ONVIF |
| Pc app access ports: | Port: 80 or cloud access (P2P) - PC: Free EZStation app |
| Power: | 12 V DC / 2 A (power adapter included) |
| Producer / brand: | UNIVIEW |
| Ptz rotary head control: | Uniview PTZ cameras |
| Recording modes: | Manual, motion detection, scheduling |
| Rtsp url: | rtsp://192.168.1.30:554/unicast/c1/s0/live - Main stream ównyrtsp://192.168.1.30:554/unicast/c1/s1/live - Auxiliary stream |
| Scales: | 0.91 kg |
| Search and play back recordings: | Search for recordings by time and type of events. Playback: forward, backward, accelerate, slow downAdvanced search (up to the second)Simultaneous playback of recordings up to 16 camerasSynchronous playback by 1/4/6/8/9/16 channels |
| Selected features: | The functions are performed in cooperation of the DVR with cameras supporting these functions Corridor mode - useful for monitoring corridors, entrance gates and narrow rooms Motion detection Sound detection IVS analysis: line crossing, intrusion, area entry detection, scene change, abandoned/missing object, face detection, counting people in a given area |
| Standard: | TCP/IP |
| Supported hard drives: | 1 x 8 TB SATA |
| Supported languages: | Polish, Czech, English, French, German, Italian, Portuguese, Slovak, Spanish |
| Supported resolutions: | .max. 8.3 Mpx 4K UHD - 3840 x 2160 px |
| Usb: | 1 x USB 2.0 1 x USB 3.0 |
| Video outputs: | 1 pc HDMI 4K1 pcs. VGA |
| Warranty: | 3 years |
| Web access ports: | 80, 554 |
Despite our best efforts, we cannot guarantee that the published technical data and photos do not contain inaccuracies or errors, which, however, cannot be a basis for claims.
