Machine tap for through holes, solid carbide
Design: factory standard, ISO 2/6H tolerance field, H type, section shape D (4–5 turns).
Application: for metric threads according to ISO DIN 13. Designed especially for steel with max. hardness 62 HRC.
Note: deviation of the diameter of the hole for thread (see table). The corresponding twist drill (Article code 1189) must be ordered separately.
HV full aluminium tap TiCN HRC62M6 GÜHRING
PLN 668.21
Shipping from warehouse: B6
Estimated shipping: Thu, Jan 29 - Mon, Feb 2
14 days returnUnconditional return policy
- Availability:
- moderate quantity
- Brand:
- GÜHRING
- Product code:
- 9029440060000 / 4031093621328
Share this product:
Specification
| Hardened steel < 55 hrc: | 4 |
|---|---|
| Hardened steel < 60 hrc: | 2, 2 |
| Jump: | 1.00 mm |
| Overall length: | 80 mm |
| Shank diameter: | 6.0 mm |
| Square grip: | 4.9 mm |
| Thread: | M6 |
| Thread hole diameter: | 5.10 mm |
Despite our best efforts, we cannot guarantee that the published technical data and photos do not contain inaccuracies or errors, which, however, cannot be a basis for claims.
