Twisting drill, cylindrical shank
Execution: DIN 340, type N.
Right-handed, with precise grinding of the top. Lateral approach angle normal, core thickness normal, convergence greater than normal.
Application: designed in particular for deep hole drilling, in alloyed and non-alloy steels and castings with a strength exceeding 800 N/mm2, for ductile iron ductile iron, sintered cast iron, high-nickel brass and graphite.
Note: other dimensions available on request.
Hollow drill DIN340 HSS, ground type N 5,80mm GÜHRING
This product is not available
- Availability:
- expected delivery
- Brand:
- GÜHRING
- Product code:
- 9002170058000 / 4031093044004
Share this product:
Specification
| Aluminium < 8% krzemu: | 45 |
|---|---|
| Cast iron gg/gts: | 27 |
| Execution: | Surface tempered in water vapour |
| Ggg cast iron: | 18 |
| Ø h7: | 5.8 mm |
| Overall length: | 139 mm |
| Spiral length: | 91 mm |
| Steel < 1000 n/mm2: | 20 |
| Steel < 700 n/mm2: | 22 |
| Steel < 700 n/mm2 f: | 0.125 mm/rev. |
Despite our best efforts, we cannot guarantee that the published technical data and photos do not contain inaccuracies or errors, which, however, cannot be a basis for claims.
