D-Link DGS-1210-10MP/E network switch Managed L2/L3 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black
€289.04
14 days returnUnconditional return policy
- Availability:
- moderate quantity
- Brand:
- Product code:
- DGS-1210-10MP / 0790069467714
Share this product:
Specification
| 10g support: | No |
|---|---|
| Ac input frequency: | 50/60 Hz |
| Ac input voltage: | 100 - 240 V |
| Access control list (acl): | Y |
| Access control list (acl) rules: | 768 |
| Arp inspection: | Y |
| Auto mdi/mdi-x: | Yes |
| Basic switching rj-45 ethernet ports quantity: | 8 |
| Basic switching rj-45 ethernet ports type: | Gigabit Ethernet (10/100/1000) |
| Broadcast storm control: | Yes |
| Cable types supported: | Cat5, Cat5e |
| Copper ethernet cabling technology: | 100BASE-TX, 1000BASE-T, 10BASE-T |
| Depth: | 180 mm |
| Dhcp features: | DHCP server, DHCP client |
| Ethernet lan data rates: | 10,100,1000 Mbit/s |
| Fiber ethernet cabling technology: | 1000BASE-X, 100BASE-FX |
| Fiber optic connector: | SFP |
| Firmware upgradeable: | Y |
| Flash memory: | 32 MB |
| Flow control support: | Yes |
| Forwarding rate: | 14.88 Mpps |
| Full duplex: | Yes |
| Half duplex: | Yes |
| Harmonized system (hs) code: | 85176990 |
| Head-of-line (hol) blocking: | Yes |
| Heat dissipation: | 507.23 BTU/h |
| Height: | 44 mm |
| Igmp snooping: | Yes |
| Installed sfp modules quantity: | 2 |
| Internal memory: | 128 MB |
| Ip-mac-port binding: | Y |
| Jumbo frames: | 10000 |
| Jumbo frames support: | Yes |
| Led indicators: | Yes |
| Link aggregation: | Yes |
| Loop protection: | Yes |
| Mac address table: | 8000 entries |
| Master (outer) cases per pallet (air): | 24 pc(s) |
| Master (outer) cases per pallet (sea): | 40 pc(s) |
| Maximum cable length: | 100 m |
| Mean time between failures (mtbf): | 1274005 h |
| Memory type: | DDR3-SDRAM |
| Multicast support: | Y |
| Networking standards: | IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z, IEEE 802.3af, IEEE 802.3az |
| Number of power supply units: | 1 |
| Number of static routes: | 256 |
| Number of vlans: | 256 |
| Operating relative humidity (h-h): | 0 - 95% |
| Operating temperature (t-t): | -5 - 50 °C |
| Package depth: | 400 mm |
| Package height: | 91 mm |
| Package weight: | 3.1 kg |
| Package width: | 319 mm |
| Packet buffer memory: | 4.1 MB |
| Pallet gross length: | 110 cm |
| Pallet gross weight (air): | 268.3 kg |
| Pallet gross weight (sea): | 430.6 kg |
| Pallet gross width: | 120 cm |
| Pallet height (air): | 118.2 cm |
| Pallet height (sea): | 188 cm |
| Port mirroring: | Yes |
| Power consumption (max): | 9.4 W |
| Power over ethernet (poe): | Yes |
| Power over ethernet (poe) ports quantity: | 8 |
| Power over ethernet plus (poe+) ports quantity: | 8 |
| Power source: | AC |
| Power supply included: | Yes |
| Product colour: | Black, Grey |
| Products per pallet (air): | 72 pc(s) |
| Products per pallet (sea): | 120 pc(s) |
| Products per shipping (inner) case: | 3 pc(s) |
| Quality of service (qos) support: | Yes |
| Safety: | CB, UL, BSMI, CCC |
| Security algorithms: | 802.1x RADIUS, SNMP, SSL/TLS, TTLS, PEAP, SSH-2, MD5, EAP |
| Sfp module slots quantity: | 2 |
| Shipping (inner) case gross weight: | 10.1 kg |
| Shipping (inner) case height: | 34.9 cm |
| Shipping (inner) case length: | 41.6 cm |
| Shipping (inner) case net weight: | 9.31 kg |
| Shipping (inner) case width: | 29.4 cm |
| Spanning tree protocol: | Yes |
| Static route: | Yes |
| Storage relative humidity (h-h): | 0 - 95% |
| Storage temperature (t-t): | -40 - 70 °C |
| Store-and-forward: | Y |
| Sustainability certificates: | cUL, CCC, BSMI, CB |
| Sustainability compliance: | Yes |
| Switch layer: | L2 |
| Switch type: | Managed |
| Switching capacity: | 20 Gbit/s |
| System event log: | Y |
| Total power over ethernet (poe) budget: | 130 W |
| Vlan support: | Yes |
| Web-based management: | Yes |
| Weight: | 1.77 kg |
| Width: | 330 mm |
