Mandrel cutter, solid carbide, corner radius
Application: can be used for HSC high-speed roughing at low ap and highest fz.
Note: for INOX treatment, use cooling.
Copy cutter HSC WNpelnow.Signum HA 4-blade.b.long 4/0,8mm Gühring
€139.68
Shipping from warehouse: B6
Estimated shipping: Fri, May 8 - Mon, May 11
14 days returnUnconditional return policy
- Availability:
- large quantity
- Brand:
- GÜHRING
- Product code:
- 9067720040000 / 4049844184879
Share this product:
Specification
| Always < 1000 n/mm²: | 85 |
|---|---|
| Always < 700 n/mm²: | 115 |
| Cast iron gg/gts: | 90 |
| Corner radius r: | 0.8 mm |
| Cutting part length l2: | 3 mm |
| Diameter d1 = h 10: | 4* mm |
| Ggg cast iron: | 20 |
| Grip ø d2 = h6: | 6 mm |
| Hardened steels < 55 hrc: | 50 |
| Hardened steels < 60 hrc: | 45 |
| Inox austenite.: | 30 |
| Inox ferrite./martenz.: | 45 |
| No: | 9067720040000 |
| Ø neck d3: | 3.8 mm |
| Shell: | Signum |
| Stink constriction l3: | 32 mm |
| Total length l1: | 80 mm |
Despite our best efforts, we cannot guarantee that the published technical data and photos do not contain inaccuracies or errors, which, however, cannot be a basis for claims.
