CODE LOCK ATLO-KRM-821-TUYA Wi-Fi

This product is not available

Availability:: expected delivery
Brand:: ATLO
Product code:: ATLO-KRM-821-TUYA / 5902887067754

Specification

Card read range:	.max. 3 cm
Card support:	Unique EM 125kHz
Case:	Metal - Narrow profile
Colour:	Silver / Black
Communication:	Wiegand 26, Wiegand 34
Dimensions:	57.5 x 120 x 21.5 mm
Maximum current consumption:	60 mA
Mobile phone access:	Possible operation via Wi-Fi using the mobile application for iOS, Android : Free Tuya Smart app for Android Free Tuya Smart app for iOS
Operating temperature:	-40 °C ... 60 °C
Permissible relative ambient humidity:	10 ... 90 % (non-condensing)
Power:	12 ... 24 volts DC
Producer / brand:	ATLO
Relay contact load:	3 A / 24 V
Scales:	0.34 kg
Sealing:	IP68
Selected features:	The integration of the device with the TUYA system additionally allows the administrator to fully remotely manage the lock from the application level: Remote door opening Remote management of users and scheduling (adding, canceling access, granting access to the user within a specified time frame) Programming one-time access codes and guest accounts with the determination of the validity period Remote access to full event history (user ID, exact date and time of access) 2000 indexed users Identification: Card and/or PIN Blue button backlight Works with exit button NO/NC output
Warranty:	3 years

External, autonomous code lock with RFID reader

Autonomous operation of the device allows the user to:
Open with a card or PIN
Remember saved cards or PINs
Signaling of a door left open
Audible and optical signaling

The administrator's capabilities are as follows:
Keyboard programming
Add a new tab using the keyboard
Add a new card and enter a PIN
Change a user's PIN
Delete a user's PIN
Lock release time setting
Restore default settings

Tuya is an international home automation platform that allows you to integrate thousands of products from different manufacturers. The system can support all the most popular communication protocols, such as Wi-Fi, Zigbee, Bluetooth

Remark! Before adding the device to the Tuya Smart app, run the pairing procedure *Administrator PIN (factory PIN 999999)#73#Control of the device and schedule settings is possible if the device has access to the Internet

Despite our best efforts, we cannot guarantee that the published technical data and photos do not contain inaccuracies or errors, which, however, cannot be a basis for claims.
