Chieftec GDP-550C power supply unit 550 W 20+4 pin ATX PS/2 Black
This product is not available
- Availability:
- expected delivery
- Brand:
- Chieftec
- Product code:
- GDP-550C / 4710713230828
Share this product:
Specification
| Ac input frequency: | 47 - 63 Hz |
|---|---|
| Ac input voltage: | 200 - 240 V |
| Atx version: | 2.3 |
| Combined power (+3.3v): | 110 W |
| Combined power (+5v): | 110 W |
| Cpu power connector (4+4 pin): | Yes |
| Depth: | 160 mm |
| Fan diameter: | 14 cm |
| Floppy drive power connector: | 1 |
| Harmonized system (hs) code: | 84733020 |
| Height: | 87 mm |
| Input current: | 4 A |
| Max output current (-12v): | 0.3 A |
| Max output current (+12v1): | 45 A |
| Max output current (+3.3v): | 20 A |
| Max output current (+5v): | 20 A |
| Max output current (+5vsb): | 2.5 A |
| Motherboard power connector: | 20+4 pin ATX |
| Number of sata power connectors: | 6 |
| Pci express power connectors (6+2 pin): | 2 |
| Peripheral (molex) power connectors (4-pin): | 3 |
| Power factor correction (pfc) type: | Active |
| Power protection features: | Overload, Short circuit, Over voltage, Overheating, Under voltage, Over current |
| Power supply unit (psu) form factor: | PS/2 |
| Product colour: | Black |
| Purpose: | PC |
| Sustainability certificates: | RoHS |
| Total power: | 550 W |
| Width: | 150 mm |
