ASRock B650M PG Lightning - bundkort -

€140.32

14 days returnUnconditional return policy

Availability:: large quantity
Brand:: ASRock
Product code:: B650M PG LIGHTNING / 4710483943829

Specification

12v power connector:	Yes
Atx power connector (24-pin):	Yes
Audio chip:	Realtek ALC897
Audio output channels:	7.1 channels
Bios type:	UEFI AMI
Cables included:	SATA
Chassis intrusion connector:	Yes
Compatible processor series:	AMD Ryzen 7000 Series
Cpu fan connector:	Yes
Depth:	244 mm
Displayport version:	1.4
Displayports quantity:	1
Ecc сompatibility:	ECC & Non-ECC
Eps power connector (8-pin):	Yes
Ethernet interface type:	2.5 Gigabit Ethernet
Ethernet lan:	Yes
Ethernet lan (rj-45) ports:	1
Front panel audio connector:	Yes
Hdcp:	Yes
Hdmi ports quantity:	1
Hdmi version:	2.1
Headphone outputs:	3
Lan controller:	Dragon RTL8125BG
Maximum internal memory:	192 GB
Maximum resolution:	3840 x 2160 pixels
Memory slots type:	DIMM
Microphone in:	Yes
Motherboard chipset:	AMD B650
Motherboard chipset family:	AMD
Motherboard form factor:	micro ATX
Number of chassis fan connectors:	3
Number of m.2 (m) slots:	3
Number of memory slots:	4
Number of sata iii connectors:	4
Number of storage drives supported:	7
Parallel processing technology support:	CrossFire
Pci express x16 (gen 3.x) slots:	1
Pci express x16 (gen 4.x) slots:	1
Processor manufacturer:	AMD
Processor socket:	Socket AM5
Product colour:	Black
Raid levels:	10, 0, 1
Raid support:	Yes
Rgb led pin header:	Yes
Screws included:	Yes
Supported memory clock speed (max):	7200 MHz
Supported memory clock speeds:	6800, 6600, 6400, 5600, 7200, 5200, 6200, 4400, 6000, 4800, 7000
Supported memory types:	DDR5-SDRAM
Supported processor sockets:	Socket AM5
Supported storage drive interfaces:	M.2, PCI Express 4.0, PCI Express 5.0, SATA III
Supported storage drive types:	HDD & SSD
Thunderbolt headers:	1
Tpm connector:	Yes
Unbuffered memory:	Yes
Usb 2.0 connectors:	2
Usb 2.0 ports quantity:	4
Usb 3.2 gen 1 (3.1 gen 1) connectors:	3
Usb 3.2 gen 1 (3.1 gen 1) type-a ports quantity:	2
Usb 3.2 gen 2 (3.1 gen 2) type-a ports quantity:	1
Usb 3.2 gen 2 (3.1 gen 2) type-c ports quantity:	1
Usb connector type:	USB Type-A, USB Type-C
Wi-fi:	No
Width:	244 mm
Windows operating systems supported:	Windows 11 x64, Windows 10 x64

B650M PG Lightning Motherboard

Supports AMD Socket AM5 Ryzen processors from the 9000, 8000, and 7000 series
6+2+1 power phase design, Dr.MOS
4 DDR5 DIMM slots
Supports Dual Channel, up to 7200+ MHz (OC)
Expansion slots: 1 × PCIe 4.0 x16, 1 × PCIe 3.0 x16, 1 × M.2 Key-E for Wi-Fi
Graphics output: HDMI, DisplayPort
Audio codec: Realtek ALC897 7.1 CH HD
Nahimic Audio support
Storage: 4 × SATA3, 1 × blazing M.2 (PCIe Gen5x4), 1 × Hyper M.2 (PCIe Gen4x4), 1 × M.2 (PCIe Gen4x2)
USB ports: 1 × USB 3.2 Gen2 Type-A+C (rear), 1 × USB 3.2 Gen1 Type-C (front), 6 × USB 3.2 Gen1 Type-A (2 rear, 4 front)
Gaming LAN: Phantom 2.5G
Supports ASRock Automatic Driver Installer and BIOS Flashback

Despite our best efforts, we cannot guarantee that the published technical data and photos do not contain inaccuracies or errors, which, however, cannot be a basis for claims.
