Aruba Instant On 1960 48G 40p Class4 8p Class6 PoE 2XGT 2SFP+ 600W Managed L2+ Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) 1U White
€1,444.75
Shipping from warehouse: A3
Estimated shipping: Wed, Oct 29 - Mon, Nov 3
14 days returnUnconditional return policy
- Availability:
- moderate quantity
- Brand:
- Hewlett-Packard
- Product code:
- JL809A#ABB / 0190017522906
Share this product:
Specification
| 10g support: | Yes |
|---|---|
| Ac input frequency: | 50 - 60 Hz |
| Ac input voltage: | 100 - 240 V |
| Access control list (acl): | Yes |
| Authentication: | Port-based authentication |
| Authentication type: | RADIUS |
| Auto mdi/mdi-x: | Yes |
| Auto-sensing: | Yes |
| Basic switching rj-45 ethernet ports quantity: | 48 |
| Basic switching rj-45 ethernet ports type: | Gigabit Ethernet (10/100/1000) |
| Built-in processor: | Yes |
| Cloud-managed: | Yes |
| Depth: | 443 mm |
| Dhcp features: | DHCP snooping |
| Flow control support: | Yes |
| Form factor: | 1U |
| Full duplex: | Yes |
| Harmonized system (hs) code: | 85176990 |
| Height: | 44 mm |
| Igmp snooping: | Yes |
| Ipv4 & ipv6 features: | IPv4/IPv6 access-control list (ACL) |
| Ipv4 fib entries: | 32 |
| Ipv6 fib entries: | 32 |
| Jumbo frames support: | Yes |
| Latency (1 gbps): | 2.2 µs |
| Latency (10 gbps): | 1.1 µs |
| Latency (10-100 mbps): | 4.4 µs |
| Link aggregation: | Yes |
| Mac address table: | 16000 entries |
| Multicast support: | Yes |
| Networking standards: | IEEE 802.3at, IEEE 802.1Q, IEEE 802.1x, IEEE 802.3bt, IEEE 802.1AX, IEEE 802.3u, IEEE 802.1ab, IEEE 802.3ad, IEEE 802.1s, IEEE 802.1D, IEEE 802.3z, IEEE 802.1w, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3az |
| Operating relative humidity (h-h): | 15 - 95% |
| Operating temperature (t-t): | 0 - 40 °C |
| Physical stacking (units): | 4 |
| Port mirroring: | Yes |
| Power over ethernet (poe): | Yes |
| Power supply included: | Yes |
| Processor frequency: | 800 MHz |
| Processor model: | ARM Cortex-A9 |
| Product colour: | White |
| Quality of service (qos) support: | Yes |
| Rack mounting: | Yes |
| Rate limiting: | Yes |
| Sfp+ module slots quantity: | 2 |
| Spanning tree protocol: | Yes |
| Ssh/ssl support: | Yes |
| Stackable: | Yes |
| Storage relative humidity (h-h): | 15 - 90% |
| Storage temperature (t-t): | -40 - 70 °C |
| Switch layer: | L2+ |
| Switch type: | Managed |
| Switching capacity: | 176 Gbit/s |
| Throughput: | 131 Mpps |
| Total power over ethernet (poe) budget: | 600 W |
| Vlan support: | Yes |
| Web-based management: | Yes |
| Weight: | 6 kg |
| Width: | 402.1 mm |
Despite our best efforts, we cannot guarantee that the published technical data and photos do not contain inaccuracies or errors, which, however, cannot be a basis for claims.
