| Alarm inputs / outputs: | 16 / 6 |
|---|
| Archiving on external media: | Screenshot of a frame of an image or recordings from an archive to a USB drive |
|---|
| Audio inputs: | 16 pcs. BNC, 1 pc(s) BNC - Microphone 32 Channels - Coaxial cable audio support, HD-CVI only |
|---|
| Audio outputs: | 1 pc BNC 1 pc BNC - Microphone |
|---|
| Colour: | Black |
|---|
| Dimensions: | 440 x 463 x 95 mm, 19" RACK, 2U |
|---|
| Image compression method: | AI Coding / H.265+ / H.265 / H.264+ / H.264 |
|---|
| Mobile phone access: | Port: 37777 or cloud access (P2P) Android: Free DMSS app iOS (iPhone): Free DMSS app Watch the video on how to configure P2P in Dahua DVRs and how to enable the mobile application |
|---|
| Motion detection: | Zoning the screen |
|---|
| Network features: | Full support via network, Remote copying of recordings, Built-in web server max. 128 users online |
|---|
| Operating modes: | 32 x AHD / HD-CVI / HD-TVI / CVBS / IP |
|---|
| Power: | 100 volts ... 240 V AC @ 50 / 60 Hz |
|---|
| Producer / brand: | DAHUA |
|---|
| Ptz rotary head control: | IP Cameras: PTZ HD-CVRS-485 - PELCO-D/P |
|---|
| Recorded image resolutions: | AHD / HD-CVI / HD-TVI: 8 Mpx - 3840 x 2160, 8M-N - 1920 x 2160, 6 Mpx - 2880 x 1920 - only HD-CVI, 5 Mpx - 2592 x 1944, 4 Mpx - 2560 x 1440, 4M-N - 1280 x 1440, 3 Mpx - 2048 x 1536 - only AHD / HD-TVI, 1080p - 1920 x 1080, 720p - 1280 x 720 CVBS: 960H - 960 x 576 IP: max. 12 MP - 4000 x 3000 |
|---|
| Recording modes: | Manual, alarm, motion detection, scheduling |
|---|
| Scales: | 6.98 kg |
|---|
| Search and play back recordings: | Search for recordings by time + timeline with recording type. Playback: forward, accelerate, decelerate, stepAdvancedSearch (up to the second) Intelligent AI face search - simultaneous search in the archive of face recordings based on max 8 photos taking into account the similarity threshold (for each photo separately)Synchronous playback divided into 1/4/9/16 channels |
|---|
| Selected features: | Cooperation with Dahua devices working in the concept of the Internet of Things (IoT), POS - cooperation with devices installed in points of sale and displaying data from them in the form of overlaid text in the selected channel window, Coax Audio/Alarm support, intelligent image analysis: line crossing, intrusion - classification of people and vehicles Advanced face recognition and search features Filtering false alarms based on person and vehicle recognition Support for up to 10 face databases, including 20,000 face photos Detection of faces not in the device database Search in face recordings based on up to 8 selected photos with the possibility of independently setting the similarity threshold for each photo SMD PLUS - search for an object classified as: human, motor vehicle, non-motor vehicle RS-232 port |
|---|
| Standard: | AHD, HD-CVI, HD-TVI, CVBS, TCP/IP |
|---|
| Supported hard drives: | 8 x 16 TB SATA + 1 x eSATA |
|---|
| Supported languages: | Polish, Czech, Danish, Dutch, English, Finnish, French, German, Greek, Hungarian, Italian, Portuguese, Romanian, Russian, Serbian, Slovak, Slovenian, Spanish |
|---|
| Usb: | 2 pcs. USB 2.0 2 pcs USB 3.0 |
|---|
| Video inputs: | 32 pcs. BNC |
|---|
| Video outputs: | 2 pcs. HDMI 4K 1 pc VGA 1 pc Video composite (BNC jack)Possibility to configure the SPOT function on one of the video outputs |
|---|
| Warranty: | 3 years |
|---|
| Write speed adjustment: | 12 Mpx IP @ 1 ... 25 fps Mpx @ 1 ... 7 fps4K-N @ 1 ... 15 fps 6 Mpx @ 1 ... 10 fps 5 Mpx @ 1 ... 12 fps / s4 Mpx @ 1 ... 15 fps / s4M-N @ 1 ... 25 fps Mpx @ 1 ... 15 fps @ 1080p @ 1 ... 25 fps @ 1 ... 25 fps @ 1 ... 25 fps per channel |
|---|
