AHD CAMERA, HD-CVI, HD-TVI, PAL HAC-HDW1500TMQ-A-0280B-S2 - 5 Mpx 2.8 mm DAHUA

Name: AHD CAMERA, HD-CVI, HD-TVI, PAL HAC-HDW1500TMQ-A-0280B-S2 - 5 Mpx 2.8 mm DAHUA
Brand: Dahua
SKU: 517712
Price: 47.84 EUR
Availability: InStock

€47.84

Shipping from warehouse: ⁨D4⁩

Estimated shipping: Mon, Apr 28 - Wed, Apr 30

14 days returnUnconditional return policy

Availability:: moderate quantity
Brand:: Dahua
Product code:: HAC-HDW1500TMQ-A-0280B-S2 / 6939554951589

Specification

Angle of rotation:	360°
Audio::	Built-in Microphone, Support audio via coaxial cable - HD-CVI only
Back light compensation (blc):	Yes
Camera pan control:	Yes
Camera tilt control:	Yes
Case::	Dome, Metal + Plastic
Colour::	white
Connectivity technology:	Wired
Day/night mode:	Yes
Dc output voltage:	12
Depth:	99.1 mm
Detect distance:	63.6 m
Digital wide dynamic range (dwdr):	Yes
Dimensions::	Ø 122 x 99 mm
Focal length range:	2.88 mm
Form factor:	Dome
Gain control type:	Auto/Manual
Height:	121.9 mm
Housing material:	Plastic, Metal
Identify distance:	6.4 m
International protection (ip) code:	IP67
Ir illuminator power adjustment::	Automatic
Ir illuminator range::	60 m
Led type:	IR
Manufacturer / brand::	DAHUA
Matrix size::	5 Mpx
Maximum aperture number:	1.6
Maximum resolution:	2880 x 1620 pixels
Minimum illumination:	0.005 lx
Mirror:	Yes
Mounting type:	Ceiling/wall
Night vision:	Yes
Noise reduction:	Yes
Noise reduction technology:	2D noise reduction
Number of cameras:	1
Objective::	2.8 mm
Observe distance:	25.4 m
Operating temperature ::	-40 °C ... 60 °C
Operating temperature (t-t):	-40 - 60 °C
Optical sensor size:	25.4 / 2.7 mm (1 / 2.7")
Osd menu::	OSD menu available via DAHUA recorder
Package weight:	600 g
Pan range:	0 - 360°
Placement supported:	Indoor & outdoor
Power consumption::	≤ 5.2 watts
Power source type:	DC
Power::	12 VDC / 440 mA
Privacy masking:	Yes
Product colour:	White
Recognize distance:	12.7 m
Resolution::	2880 x 1620 - 5 Mpx - HD-CVI only: Aspect ratio 16: 9 ,2560 x 1440 - 3.7 Mpx ,1920 x 1080 - 1080p - HD-CVI only, 960 x 576 - 960H, PAL
Scales::	0.43 kg
Sealing::	IP67
Selected features::	D-WDR - Wide Dynamic Range 2D-DNR - Digital BLC/HLC Image Noise Reduction - Background Light / Strong Light ICR Compensation - Mechanical IR Filter AGC Day/Night Mode - Auto Image Gain Adjustment Auto White Balance Privacy Zone Mirror - Sharpness Image Mirror - Sharpness Image Contour Sharpening
Sensor type:	CMOS
Signal-to-noise ratio (snr):	65 dB
Smart ir:	Yes
Standard::	HD-CVI, HD-TVI, AHD, CVBS
Storage temperature (t-t):	-40 - 60 °C
Supported graphics resolutions:	2880 x 1620
Tilt angle range:	0 - 78°
Total megapixels:	5 MP
Transducer::	1/2.7" Progressive Scan CMOS
Type:	IP security camera
Video output::	AHD / HD-CVI / HD-TVI / CVBS, 1 Vpp / 75 Ω
Viewing angle::	111° (manufacturer data) 107° (our tests)
Warranty::	3 years
Weight:	400 g
White balance:	Auto, Manual
Width:	99.1 mm

Megapixel camera with 1/2.7" CMOS sensor and AHD / HD-CVI / HD-TVI / CVBS interface

The AHD / HD-CVI / HD-TVI interface allows the transmission of analog video signal via coaxial cable in max. 8 Mpx (4K UHD)There are no delays during transmission and the original, high image quality is maintained

In the case of video transmission by means of twisted pair and transformers adjusting the impedance, it is necessary to bear in mind the possibility of signal reflections and the penetration of signals between each otherThe illuminator range given by the manufacturer depends on the environmental conditions (air transparency, environment, wall color, i.e. the so-called scene reflectance)

The camera meets ip67 protection class

Despite our best efforts, we cannot guarantee that the published technical data and photos do not contain inaccuracies or errors, which, however, cannot be a basis for claims.
