| Access from a mobile phone:: | Port: 37777 or cloud access (P2P) Android: Free DMSS iOS app (iPhone): Free DMSS app |
|---|
| Alarm inputs / outputs:: | 1 / 1 |
|---|
| Audio:: | External Microphone Input Audio Output Sound Detection |
|---|
| Case:: | Dome - Metal |
|---|
| Colour:: | white |
|---|
| Default administrator login / password:: | admin / -Administrator password should be set at first startup |
|---|
| Default ip address:: | 192.168.1.108 |
|---|
| Dimensions:: | Ø 159 x 118 mm |
|---|
| Image compression method:: | H.265+ / H.265 / H.264+ / H.264 / MJPEG |
|---|
| Ir illuminator range:: | 40 m |
|---|
| Main stream transmission speed:: | 25 fps @ 1080p |
|---|
| Manufacturer / brand:: | DAHUA |
|---|
| Matrix size:: | 2.1 Mpx |
|---|
| Max. number of on-line users:: | 20 |
|---|
| Memory card slot:: | Supports Micro SD cards up to 256GB (local write possible) |
|---|
| Network interface:: | 10/100 Base-T (RJ-45) |
|---|
| Network protocols:: | IPv4/IPv6, HTTP, HTTPS, TCP, UDP, ARP, RTP, RTSP, RTCP, RTMP, SMTP, FTP, SFTP, DHCP, DNS, DDNS, PPPoE, SNMP, QoS, UPnP, NTP, Multicast, ICMP, IGMP, NFS, PPPoE, IEEE 802.1x, SNMP |
|---|
| Objective:: | 2.7 ... 13.5 mm - Motozoom |
|---|
| Onvif port:: | 80 |
|---|
| Onvif:: | 18.12 |
|---|
| Operating temperature :: | -30 °C ... 60 °C |
|---|
| Port of access via mobile application:: | 37777 |
|---|
| Ports for access via the pc application:: | 37777 |
|---|
| Power consumption:: | ≤ 11.8 watts |
|---|
| Power:: | PoE (802.3af), ePoE, 12 V DC / 980 mA, 24 V AC / 490 mA |
|---|
| Resolution:: | 1920 x 1080 - 1080p1280 x 960 - 1.3 Mpx1280 x 720 - 720p |
|---|
| Rtsp url:: | rtsp://admin:password o@192.168.1.108:554/cam/realmonitor?channel=1&subtype=0 - Stream mainrtsp://admin:password o@192.168.1.108:554/cam/realmonitor?channel=1&subtype=1 - Secondary stream |
|---|
| Scales:: | 0.88 kg |
|---|
| Sealing:: | IP67 |
|---|
| Selected features:: | Motozoom WDR Lens - 120 dB - Wide Dynamic Range 3D-DNR - Digital Noise Reduction in EIS - F-DNR Electronic Image Stabilization (Defog) - Noise Reduction ROI - Improving the Quality of Selected BLC Image Fragments - Configurable HLC Backlight Compensation - Strong Light (Spot) ICR Compensation - Mechanical IR Filter Motion Detection Customizable Privacy Zones Auto White Balance Sharpness - Sharpening image contours Mirror - Mirror image Heat map - color-coded areas of different traffic in the image IVS analysis: line crossing, intrusion - classification of people and vehicles, abandoned/missing object, illegal parking, detection of gathering of people, counting people - support for 4 independent detection areas, face detection - supports 6 types of extraction of face attributes |
|---|
| Standard:: | TCP/IP |
|---|
| Supported languages:: | Polish, Czech, English, French, German, Italian, Portuguese, Russian, Spanish |
|---|
| Transducer:: | 1/2.8" STARVIS™ CMOS |
|---|
| Vandal proof:: | IK10 |
|---|
| Viewing angle:: | 109 ° ... 30° (manufacturer data) 104° ... 31° (our tests) |
|---|
| Warranty:: | 3 years |
|---|
| Web access ports:: | 80, 37777 |
|---|
| Web server:: | Built-in, Web Viewer |
|---|
