Linksys LGS310MPC Managed L3 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black
This product is not available
- Availability:
- expected delivery
- Brand:
- Product code:
- LGS310MPC-EU / 4260184670642
Share this product:
Specification
| 10g support: | No |
|---|---|
| Ac input frequency: | 50 - 60 Hz |
| Ac input voltage: | 100 - 240 V |
| Access control list (acl): | Yes |
| Authentication: | Guest VLAN |
| Authentication type: | RADIUS |
| Basic switching rj-45 ethernet ports quantity: | 8 |
| Basic switching rj-45 ethernet ports type: | Gigabit Ethernet (10/100/1000) |
| Broadcast storm control: | Yes |
| Depth: | 240 mm |
| Dhcp features: | DHCP snooping, DHCP client, DHCP relay |
| Firmware upgradeable: | Yes |
| Forwarding rate: | 14.88 Mpps |
| Gigabit ethernet (copper) ports quantity: | 8 |
| Harmonized system (hs) code: | 85176990 |
| Head-of-line (hol) blocking: | Yes |
| Height: | 26.9 mm |
| Housing material: | Metal |
| Igmp snooping: | Yes |
| Input current: | 2.2 A |
| Internal memory: | 256 MB |
| Ip-mac-port binding: | Yes |
| Ipv4 fib entries: | 63 |
| Ipv6 fib entries: | 21 |
| Jumbo frames: | 10000 |
| Jumbo frames support: | Yes |
| Led indicators: | Power, Fault |
| Link aggregation: | Yes |
| Loop protection: | Yes |
| Mac address table: | 8000 entries |
| Management protocols: | HTTP, HTTPS |
| Master (outer) case gross weight: | 10.3 kg |
| Master (outer) case height: | 302.3 mm |
| Master (outer) case length: | 540 mm |
| Master (outer) case width: | 178.3 mm |
| Memory type: | DRAM |
| Multicast support: | Yes |
| Networking standards: | IEEE 802.3, IEEE 802.3ab, IEEE 802.1x, IEEE 802.1Q, IEEE 802.3x, IEEE 802.3ad, IEEE 802.1s, IEEE 802.3u, IEEE 802.3af, IEEE 802.3az, IEEE 802.1D, IEEE 802.3z, IEEE 802.1w |
| Number of vlans: | 256 |
| Operating relative humidity (h-h): | 10 - 90% |
| Operating temperature (t-t): | 0 - 40 °C |
| Package depth: | 281.4 mm |
| Package height: | 101.1 mm |
| Package type: | Box |
| Package weight: | 1.92 kg |
| Package width: | 156.6 mm |
| Port mirroring: | Yes |
| Power consumption (max): | 133.77 W |
| Power over ethernet (poe): | Yes |
| Power over ethernet plus (poe+) ports quantity: | 8 |
| Power source: | AC |
| Power supply included: | Yes |
| Product colour: | Black, Blue |
| Products per master (outer) case: | 5 pc(s) |
| Quality of service (qos) support: | Yes |
| Rate limiting: | Yes |
| Security algorithms: | SNMP, HTTPS |
| Sfp+ module slots quantity: | 2 |
| Spanning tree protocol: | Yes |
| Ssh/ssl support: | Yes |
| Stackable: | Yes |
| Static port security: | Yes |
| Storage relative humidity (h-h): | 5 - 95% |
| Storage temperature (t-t): | -20 - 70 °C |
| Switch layer: | L3 |
| Switch type: | Managed |
| Switching capacity: | 20 Gbit/s |
| Virtual lan features: | Port-based VLAN |
| Vlan support: | Yes |
| Weight: | 288.5 g |
| Width: | 104.9 mm |
Despite our best efforts, we cannot guarantee that the published technical data and photos do not contain inaccuracies or errors, which, however, cannot be a basis for claims.
